Products may differ in size, colour and appearance to those shown. If you require further information or customisation, please contact us directly.
WISKA-Order no. | 10015140 |
Type | 2000/B22/ye |
Material | PBT |
Material globe/diffuser | Polycarbonate |
Globe colour | Yellow |
Power^ | 1 x 75 W |
Wattage | 75 W |
Voltage | 230 V |
Protection class | IP68 (2,0 bar 30min) |
Temp. range min | -30 °C |
Temp. range max | 45 °C |
Lampholder | B22d |
Number of lampholder | 1 ST |
Lightsource | variable, Incandescent lamp |
Lightsource incl. | No |
Bulb shape | Rod shaped |
Material cable gland | Polyamide |
Type of cable gland | ESKV 20 PLUS / 7,5-14mm |
Using for cable gland | |
Ø cable diameter min | 7,5 mm |
Ø cable diameter max | 14 mm |
External dimensions LxWxH | 134x240mm |
Weight | 0,58 kg |
Approval | RMRS, DNV-GL |
Colour | Black |
Mounting | Upside down, Upside, Surface mounting, Ceiling |
Equipment | 4 threaded knockout entry M20 |
Tariff number | 85318070 |
Equipment: - Plastic: impact resistant, heat-and water resistant - 4 threaded knockout entries M20 - Separate terminal to loop the armour - 2 cable glands ESKV 20 enclosed separately |
