Products may differ in size, colour and appearance to those shown. If you require further information or customisation, please contact us directly.
| WISKA-Order no. | 10015140 |
| Type | 2000/B22/ye |
| Material | PBT |
| Material globe/diffuser | Polycarbonate |
| Globe colour | Yellow |
| Power^ | 1 x 75 W |
| Wattage | 75 W |
| Voltage | 230 V |
| Protection class | IP68 (2,0 bar 30min) |
| Temp. range min | -30 °C |
| Temp. range max | 45 °C |
| Lampholder | B22d |
| Number of lampholder | 1 ST |
| Lightsource | variable, Incandescent lamp |
| Lightsource incl. | No |
| Bulb shape | Rod shaped |
| Material cable gland | Polyamide |
| Type of cable gland | ESKV 20 PLUS / 7,5-14mm |
| Using for cable gland |
 |
| Ø cable diameter min | 7,5 mm |
| Ø cable diameter max | 14 mm |
| External dimensions LxWxH | 134x240mm |
| Weight | 0,58 kg |
| Approval | RMRS, DNV-GL |
| Colour | Black |
| Mounting | Upside down, Upside, Surface mounting, Ceiling |
| Equipment | 4 threaded knockout entry M20 |
| Tariff number | 85318070 |
| Equipment: - Plastic: impact resistant, heat-and water resistant - 4 threaded knockout entries M20 - Separate terminal to loop the armour - 2 cable glands ESKV 20 enclosed separately |
|
DNV-GL-HNA Luminares_C-EN
