WISKA-Order no. | 10106099 |
Type | SO-16A-MS-L-500V-4P-3H-IP56-Z14 |
Material | Brass |
Material protective cap | Polyamide |
Voltage max. (V) | 500 V |
Type of Voltage | AC |
Current | 16 A |
Socket insert | 3 - poles + PE |
Protection class | IP56 |
Temp. range min | -25 °C |
Temp. range max | 45 °C |
Clock face position | 3h |
Type of cable gland | M24x1,5 Z 14 / 12-14,5mm |
Ø cable diameter min | 12 mm |
Ø cable diameter max | 14,5 mm |
Type of cable | armoured |
Mounting | Surface mounting |
Weight | 2 kg |
Variations | on request |
Tariff number | 85366990 |
Remarks: CEE-power socket 16A without switch Material: Brass/red brass, plastic bayonett cap Equipment: without switch, without locking mechanism, according to DIN EN 60309, CEE 17/2, IEC 309, Protection class: IP56 Terminal/Poles 3-pole + PE Clock face position protective earthconductor: 3h cable entry: 1xM24/1,5 -O for armoured cable 12-14,5mm in diameter |
